Product name: 1,3-Bis (N, N-diglycodylaminomethyl) cyclohexanone

CAS: 65992-66-7

Molecular formula: C20H34N2O4

Molecular weight: 366.50

Physical and chemical properties

Appearance: Colorless to light yellow transparent viscous liquid

Density (20 ℃): 1.18 g/cm ³

Refractive index n ₂₀/D: 1.546

Flash point: 140 ℃

Viscosity (25 ℃): 1500-3000 mPa · s

Epoxy equivalent: 95-110 g/eq; Epoxy value: 0.90-1.05 eq/100g

Solubility: soluble in organic solvents such as epoxy resin, acetone, toluene, dichloromethane, etc; Slightly soluble in water.

Characteristics: Four functional group glycidyl amine epoxy resin, high reactivity, high curing crosslinking density; The cured material has excellent high temperature resistance, high modulus, radiation resistance, low shrinkage, and electrical insulation performance.

Main use

High performance epoxy matrix resin: carbon fiber, glass fiber reinforced composite materials, aerospace, military composite material matrix.

High temperature resistant adhesive: structural adhesive, bonding under high temperature conditions.

Electronic and electrical materials: IC/LSI integrated circuit potting material, insulation casting material, high-voltage electrical insulation components.

Solvent free high-temperature resistant epoxy coating and anti-corrosion coating.

High temperature resistant active epoxy diluent, used for high temperature resistant epoxy systems, does not significantly reduce the thermal deformation temperature of the system; It can also be used as a crosslinking agent for acrylic adhesives to enhance the heat resistance and adhesion of pressure-sensitive adhesives.

Quality indicators (industrial grade)

Appearance: Colorless to pale yellow clear viscous liquid

Gardner Color: ≤8

Viscosity(25℃):1500‑3000 mPa·s

Epoxy Value:0.90‑1.05 eq/100g

Epoxy Equivalent:95‑110 g/eq

Moisture(KF): ≤0.15%

Packaging

Large packaging: 200L galvanized iron drum, net weight 200kg/drum

Small and medium-sized packaging: 20kg plastic drum; 1kg/5kg small sample bucket

Storage, transportation, and compliant

The lid of the barrel must be sealed to prevent moisture absorption and premature reaction with epoxy groups; Shelf life is 6 months.

GHS hazards: skin corrosion/irritation, severe eye irritation; May cause skin sensitization.

Not classified as easily producible drugs, easily producible explosives, or dual-use items; Non dangerous goods general cargo transportation, without UN number.

Handle with care during loading and unloading to prevent damage and leakage of the barrel, and protect against rain and sun.
